Carve Power Led


Brand: IMTRA

SKU: N/A Categories: , Tag:


Carve Power led

Featuring 2-wire power & dimming, Carve easily replaces existing legacy (halogen) spots negating the need to run extra wires. Integrated drive electronics eliminates the need for remote driver installation. Carefully designed optics result in fully blended illumination free of annoying artifacts or distracting hot spots. A robust thermal management system results in maximum life with minimal lumens depreciation over its expected working life (50,000+ hrs). Carve offers single or bi-color dimming when paired with Imtra’s single or dual channel PWM dimmer module. Carve features a small diameter, ultra-flat, molded square bezel in a mirror polished, matte chrome or custom finish. Carve conveniently & firmly installs with self-adjusting stainless steel springs. Made in the USA and covered by a 5-year warranty!

Product Specs

Weight 1 lbs


Color Led

Cool White, Cool White/Blue, Cool White/Red, Red/Blue/Warm, Warm White, Warm White/Blue

Frame color

Chrome Plated, Matte Chrome Plated

Mounting / Cut

2.65" (67mm)

Trim Ring (Bezel)

3.14″ x 3.14″ (80 x 80mm)

IP Rating





Black Electrophoretic

Certifications & Compliance


Technical data

Housing Finish/Material Black Electrophoretic Aluminum
Certifications & Compliance CE-EMC, ROHS
Integrated Switch No
Output Color Warm White
Lifetime Hours 50,000 hrs
Class Class III
Dimmer Control Interface Momentary Push-Button
Cut-out Dimensions 2.65″ (67mm)
Trim Ring (Bezel) Dimensions 3.14″ x 3.14″ (80 x 80mm) dia
Trim Ring (Bezel) Finish/Material Chrome Plated/PC
Halogen Equivalency 25W
Input Voltage 10-40VDC
Warranty 5 Years / 1 Year Finish
Power Consumption 4.7W
Recessed Depth 1.05″ (27mm)
Lens Material Frosted glass
Ingress Protection IP65 (applies only to frontal water exposure, i.e. Exposed surface)
Dimming Range 5-100%
Luminous Flux 183 lms
Driver Integrated
Install Location Ceilings (interior)
Electrical Protections Reverse Polarity, Transient & Spike Protection
Correlated Color Temperature (CCT) 2800K (White LED)
Color Rendering Index (CRI) 85
Approximate Ship Weight (lbs) 1
