Power Supply Universal 60W 12V

Power Supply Universal 60W 12V

The LUMIRON Power Supply Universal 60W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4500
  2. Model: LMPS60S12VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.4A
  6. Output Current: 5A
  7. Maximum Output Power: 60 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 4.9″ x W 1.9″ x H 1.2″ / L ( 12.5cm ) x W ( 4.9cm ) x H ( 3.1cm )
Power Supply Universal 60W 24V

Power Supply Universal 60W 24V

The LUMIRON Power Supply Universal 60W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4501
  2. Model: LMPS60S24VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63 / 1.4A
  5. Output Current: 2.5A
  6. Maximum Output Power: 60 Watts
  7. Output Connector Type: Cylindrical Female
  8. Output Connector Diameters: 2.1mm x 5.5mm
  9. Efficiency: 88%
  10. Type: Switching
  11. Style: Desktop Adapter
  12. Case: Fully enclosed plastic case
  13. Protections: Short circuit / Overload / Over voltage / Over temperature
  14. Size: L 4.9″ x W 1.9″ x H 1.2″ / L ( 12.5cm ) x W ( 4.9cm ) x H ( 3.1cm )
Power Supply Universal 120W 12V

Power Supply Universal 120W 12V

The LUMIRON Power Supply Universal 120W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4502
  2. Model: LMPS120S12VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.4A
  6. Output Current: 8.5A
  7. Maximum Output Power: 102 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 6.57″ x W 2.63″ x H 1.37″ / ( 16.7cm ) x W ( 6.7cm ) x H ( 3.5cm )
Power Supply Universal 120W 24V

Power Supply Universal 120W 24V

The LUMIRON Power Supply Universal 120W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4503
  2. Model: LMPS120S24VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.4A
  6. Output Current: 5A
  7. Maximum Output Power: 122 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 91%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 6.67″ x W 2.63″ x H 1.37″ / ( 16.7cm ) x W ( 6.7cm ) x H ( 3.5cm )
Power Supply Universal 90W 12V

Power Supply Universal 90W 12V

The LUMIRON Power Supply Universal 90W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4510
  2. Model: LMPS90S12VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 2.6A
  6. Output Current: 5A
  7. Maximum Output Power: 90 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 5.71″ x W 2.36″ x H 1.26″ / L ( 14.5cm ) x W ( 6.0cm ) x H ( 3.2cm )
Power Supply Universal 90W 24V

Power Supply Universal 90W 24V

The LUMIRON Power Supply Universal 90W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4511
  2. Model: LMPS90S24VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.3A
  6. Output Current: 3.75A
  7. Maximum Output Power: 90 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 5.71″ x W 2.36″ x H 1.26″ / L ( 14.5cm ) x W ( 6.0cm ) x H ( 3.2cm )
DMR 3007 PB 1 Zone Dimmer Receiver Amplifier

DMR 3007 PB 1 Zone Dimmer Receiver Amplifier

It is a wireless dimming and ON/OFF system for any LED Product that works at 12VDC, 24VDC, or 36VDC. The 800mhz wireless remote can be placed anywhere and works as an ON/Off switch and dimmer with just one button. Easily adjust your LED Lights to your preferred brightness level and the unit will memorize the setting, so next time you turn on the lights they will light up at exactly the same level they were before they were turned off. The DMR 3007 PB 1 Zone Dimmer Receiver Amplifier product includes a PUSH BUTTON WIRELESS DIMMER and one UL Listed RECEIVER ensuring the safety and durability for the lifetime of the receiver. It is IP20, please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a waterproof enclosure. Always be sure to mount it in an area with proper ventilation to avoid overheating. It is easy to install and operate and will provide many years of easy operation. The operation is very simple: Press the center button on the remote for less than 1 second to turn On or OFF. Press and hold the button to Increase/Decrease brightness.

Main Features

  • Ultra compact Wireless Dimmer remote (1.51in x 0.70in)
  • Battery included with remote
  • On/Off function
  • 0-100% dimming
  • 4 X 120W Outputs (total 480W @24VDC)
  • Memory function (keeps settings even if power loss)
  • Ultra smooth dimming
  • Remote Control unit can be hidden almost everywhere
  • Up to 30 feet control distance (Unobstructed)
DMR 3009 WM 2 Zone Dimmer Receiver Amplifier

DMR 3009 WM 2 Zone Dimmer Receiver Amplifier

It is a wireless dimming and ON/OFF system for any LED Product that works at 12VDC, 24VDC, or 36VDC. It has been designed to bring light control easily. No wires or switch box locations are needed, just stick or mount it to any flat location such as walls or cabinets. The simple modern design and elegant Ivory White surface complement a variety of LED projects. The dimmer switch features smooth and accurate dimming from 0.1%-100% without any flickering. It can also control up to four single colors LED fixtures at once, and has two zones for LED lights at either 12VDC or 24VDC. After the installation is complete, you can change the brightness from 0% to 100% brightness. The DMR 3009 WM 2 Zone Dimmer Receiver Amplifier runs on a single internal 3V CR2430 battery (included) and includes a receiver. The wireless design saves time and energy by requiring no cabling or installation to pair it with the LED zone. It is IP20, please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a waterproof enclosure. Always be sure to mount it in an area with proper ventilation to avoid overheating. It is easy to install and operate and will provide many years of easy operation.

Main Features

  • No Wires, Stick or Mount to Any Flat Surface
  • Wireless Control of Any LED Lights
  • On/Off function
  • 0-100% dimming
  • 4 X 120W Outputs (total 480W @24VDC)
  • Memory function (keeps settings even if power loss)
  • Ultra smooth dimming
  • Elegant Ivory White Glass Surface
  • 50 Foot Wireless Range
DMR 3010 PB 1 Zone Wired Wireless Dimmer Controller

DMR 3010 PB 1 Zone Wired Wireless Dimmer Controller

Lumiron’s DMR 3010 PB 1 Zone Wired Wireless Dimmer Controller is the perfect companion for multiple Lumiron’s wireless LED Dimmers and is also great for adding extra zones for additional areas or projects. Designed for single color LED fixtures and single zone application, this small yet powerful unit has 8 amps per channel delivering an outstanding max power of 192W at 24V DC. The DMR 3010 PB 1 Zone Wired Wireless Dimmer Controller includes an array of innovative features such as a memory function which will remember your last setting in case of a power outage, soft ON/OFF for smooth light illumination as well as smooth dimming levels from 0 – 100%, flicker-free lighting, and the Learning Key button which allows for seamless pairing with your wireless LED Remote. The addition of the Push-Switch Terminal is added for momentary switch applications and incorporates a detachable terminal for easy wire-in installations to the unit.

Main Functions

  • Low-Profile – Lightweight LED Controller
  • Great for Adding Extra Zones for Single Color LED Fixtures
  • Perfect Companion for Various Solid Apollo Dimmers
  • Detachable Push-Switch Terminal for Easy Wiring Installation
  • Soft On/Off for Smooth Light Illumination
  • Learning Key Button Ensures Quick and Seamless Pairing
  • Memory Function – Remembers Last Setting even if Power Goes Off

Warning: You can only control one zone with this controller. If you need to control multiple zones you will need one controller for each zone.

3 Zones RGB Controller

3 Zones RGB Controller

3 Zones RGB Controller is a simple controller that lets you control up to 3 independent channels with 0-100% power rotary knobs. Thanks to its simplicity you can fine tune the any desired color in a color changing LED strip by incrementing or decreasing the RED, BLUE or Green Colors. Installation is quite easy, just power up the unit in with 12 to 24V DC power source and connect the 3 outputs to and RGB LED strip or a Solid Color LED strip. Power and outputs cables are easily connected to the unit through screw down connectors, which make 100% secure connections. Perfect to use in LUMIRON’s Dakota LED Panel

Uses:
– For RGB Led Strip controlling and dimming each color independently
– Excellent for solid color LED Strips with 3 independent channels, also for Dynamic White LED strip, controlling color temperature.
