Ripple Power led

$98.04$129.70

Brands: IMTRA

Quantity discounts
1-5 6-15 16+
$120.65 $118.11 $117.00
Quantity discounts
1-5 6-15 16+
$120.65 $118.11 $117.00
Quantity discounts
1-5 6-15 16+
$91.20 $89.28 $86.00
Quantity discounts
1-5 6-15 16+
$91.20 $89.28 $86.00
Clear
SKU: N/A Categories: ,
Loading...

Description

DOWNLIGHTS RIPPLE Power Led

LED LIGHTING DOWNLIGHTS RIPPLE Power Led is  Ideal for boat, yacht, RVs, motor home and more. Featuring 2-wire power & dimming, Ripple easily replaces existing legacy (halogen) spots negating the need to run extra wires. Integrated drive electronics eliminates the need for remote driver installation. Carefully designed optics result in fully blended illumination free of annoying artifacts or distracting hot spots.

A robust thermal management system results in maximum life with minimal lumens depreciation over its expected working life (50,000+ hrs). Ripple offers single or bi-color dimming when paired with Imtra’s single or dual channel PWM dimmer module.  features a round bezel with rounded radius edge. Ripple is securely mounted with three screws and is ideal for hard ceilings (e.g. fiberglass or wood). It is a good choice for wet areas (e.g. hard tops, arches, walkway overhangs, shower stalls). Made in the USA and covered by a 5-year warranty!

VIEW MORE DOWNLIGHTS

Weight 1 lbs
Color Led

Cool White, Cool White/Blue, Warm White, Warm White/Red

Frame color

Polished SS

Mounting / Cut

2.40″ (61mm)

Trim Ring (Bezel)

3.80″ (96mm)

IP Rating

IP65

Brand

IMTRA

Technical data

Housing Finish/Material  Black Electrophoretic Aluminum
Certifications & Compliance CE-EMC, ROHS
Integrated Switch No
Lifetime Hours 50,000 hrs
Class Class III
Dimmer Control Interface Momentary Push-Button
Cut-out Dimensions 2.40″ (61mm)
Trim Ring (Bezel) Dimensions 3.80″ (96mm) dia
Trim Ring (Bezel) Finish/Material Polished stainless steel
Halogen Equivalency 25W
Input Voltage 10-40VDC
Warranty 5 Years / 1 Year Finish
Power Consumption 4.7W
Recessed Depth 1.05″ (27mm)
Lens Material Frosted glass
Ingress Protection IP65 (applies only to frontal water exposure, i.e. Exposed surface)
Dimming Range 5-100%
Luminous Flux 183 lms
Driver Integrated
Install Location Exterior (hard tops, overhangs, showers)
Electrical Protections Reverse Polarity, Transient & Spike Protection
Correlated Color Temperature (CCT) 2800K (White LED)
Color Rendering Index (CRI) 85
Approximate Ship Weight (lbs) 1
