Sigma Power Led

$159.00$195.00

Brand: IMTRA

SKU: N/A Categories: , Tag:
Loading...

Description

Sigma Power Led

The Tri-Color Series is a comprehensive range of recessed and surface-mount downlights featuring the ability to select from three different LED colors (e.g. Red/Blue/Cool White or Red/Blue/Warm White). Only two wires provide both power to unit(s) and signal to change colors. Advancing through the colors is achieved by toggling a (user supplied) single on/off switch. Choose from a wide range of bezel styles and different mounting methods. Spring mount-models are recommended for interior spaces and soft panel headliners. The screw-mounted fixtures provide exceptional sealing and are recommended wet areas or for exterior applications.

Product Specs

Weight 1 lbs
Brand

IMTRA

Color Led

Cool White, Red/Blue/Cool White, Red/Blue/Warm White

Frame color

Brushed SS, Polished SS, Stainless Steel

Mounting / Cut

4.07" (103mm)

Trim Ring (Bezel)

3.57″ (91mm)

IP Rating

IP65

Certifications & Compliance

RoHS

Lifetime Hours

50,000 hrs

Class

Class III

CCT

2800K

CRI

83

Luminous Flux

197 lms

Technical data

Certifications & Compliance ROHS
Integrated Switch No
Output Color RED/BLUE/CW
Lifetime Hours 50,000 hrs
Class Class III
Dimmer Compatibility Intervolt Switchmode DC Dimmers
Cut-out Dimensions 2.56″ (65mm)
Trim Ring (Bezel) Dimensions 3.57″ (91mm)
Trim Ring (Bezel) Finish/Material Polished stainless steel
Halogen Equivalency 25W
Input Voltage 10-40VDC
Warranty 5 Years / 1 Year Finish
Power Consumption 5.0W
Recessed Depth 0.90″ (23mm)
Lens Material Acrylic
Ingress Protection IP65 (applies only to frontal water exposure, i.e. Exposed surface)
Mounting Method Screw-mount
Luminous Flux 197 lms
Driver Integrated Constant-Current
Install Location Exterior
Electrical Protections Reverse Polarity, Transient
Correlated Color Temperature (CCT) 5500K
Approxaimte Ship Weight (lbs) 1
