T180 Power led

$178.72$188.93

Brands: IMTRA

Quantity discounts
1-5 6-15 16+
$166.25 $162.75 $157.50
Quantity discounts
1-5 6-15 16+
$175.75 $172.05 $166.50
Quantity discounts
1-5 6-15 16+
$166.25 $162.75 $157.50
Quantity discounts
1-5 6-15 16+
$175.75 $172.05 $166.50
Quantity discounts
1-5 6-15 16+
$166.25 $162.75 $157.50
Quantity discounts
1-5 6-15 16+
$166.25 $162.75 $157.50
Clear
SKU: N/A Categories: ,
Loading...

Description

DOWNLIGHTS T180 Power Led

LED LIGHTING DOWNLIGHTS T180 Power Led is  Ideal for boat, yacht, RVs, motor home and more. Featuring 2-wire power & dimming, T155/180 PowerLED fixtures easily replace existing legacy (halogen) spots negating the need to run extra wires. Integrated drive electronics eliminates the need for remote driver installation. Carefully designed optics result in fully blended illumination free of annoying artifacts or distracting hot spots.

A robust thermal management system results in maximum life with minimal lumens depreciation over its expected working life (50,000+ hrs). T155/180 models offer single or bi-color dimming when paired with single or dual channel PWM dimmer module. These fixtures feature a traditional raised-round bezel in several finishes. The T155/180 PowerLEDs securely mounted with three screws and are ideal for hard ceilings (e.g. fiberglass or wood). It is a good choice for wet areas (e.g. hard tops, arches, walkway overhangs, shower stalls). Made in the USA and covered by a 5 year warranty!

VIEW MORE DOWNLIGHTS

Weight 1 lbs
Color Led

Cool White, Cool White/Blue, Warm White

Frame color

Polished SS, white

Mounting / Cut

5.10″ (130mm)

Trim Ring (Bezel)

7.09″ (180mm)

IP Rating

IP65

Brand

IMTRA

Technical data

Certifications & Compliance CE-EMC, ROHS
Integrated Switch No
Lifetime Hours 50,000 hrs
Class Class III
Dimmer Control Interface Momentary Push-Button
Cut-out Dimensions 5.10″ (130mm)
Trim Ring (Bezel) Dimensions 7.09″ (180mm)
Halogen Equivalency 25W
Input Voltage 10-40VDC
Warranty 5 Years / 1 Year Finish
Lens Material Frosted glass
Recessed Depth 1.08″ (27mm)
Ingress Protection IP65 (applies only to frontal water exposure, i.e. Exposed surface)
Dimming Range 5-100%
Luminous Flux 206 lms
Driver Integrated
Install Location Exterior (hard tops, overhangs, showers)
Electrical Protections Reverse Polarity, Transient & Spike Protection
Correlated Color Temperature (CCT) 6000K (White LED)
Color Rendering Index (CRI) 85
Approximate Ship Weight (lbs) 1
