TCM155 24 led
DOWNLIGHTS TCM155 24 LED
LED LIGHTING DOWNLIGHTS TCM155 24 LED is Ideal for boat, yacht, RVs, motor home and more. Featuring 2-wire power & dimming, TCM155 24 LED fixtures easily replace existing legacy (halogen) spots negating the need to run extra wires. Integrated drive electronics eliminates the need for remote driver installation. Carefully designed optics result in fully blended illumination free of annoying artifacts or distracting hot spots.
A robust thermal management system results in maximum life with minimal lumens depreciation over its expected working life (50,000+ hrs). These fixtures feature a traditional raised-round bezel in several finishes. The securely mounted with three screws and are ideal for hard ceilings (e.g. fiberglass or wood). It is a good choice for wet areas (e.g. hard tops, arches, walkway overhangs, shower stalls). Made in the USA and covered by a 5 year warranty!
| Weight | 1 lbs |
|---|---|
| Color Led | Amber, Blue, Cool White 6500K, Green, Neutral White 4500K, Red, Warm White 3000K |
| Input Voltage | 12-36V AC/DC, 12V AC/DC, 24V AC/DC |
| Mounting / Cut | 5.10″ (130mm) |
| Trim Ring (Bezel) | 7.09″ (180mm) |
| IP Rating | IP65 |
| Brand | Lumiron |
Technical data
| No. LEDs | 24 |
| Certifications & Compliance | CE-EMC, ROHS |
| Integrated Switch | No |
| Lifetime Hours | 50,000 hrs |
| Class | Class III |
| Dimmer Control Interface | Momentary Push-Button |
| Cut-out Dimensions | 5.10″ (130mm) |
| Trim Ring (Bezel) Dimensions | 7.09″ (180mm) |
| Halogen Equivalency | 25W |
| Input Voltage | 10-40VDC |
| Warranty | 5 Years / 1 Year Finish |
| Lens Material | Frosted glass |
| Recessed Depth | 1.08″ (27mm) |
| Ingress Protection | IP65 (applies only to frontal water exposure, i.e. Exposed surface) |
| Dimming Range | 5-100% |
| Luminous Flux | 206 lms |
| Driver | Integrated |
| Install Location | Exterior (hard tops, overhangs, showers) |
| Electrical Protections | Reverse Polarity, Transient & Spike Protection |
| Color Rendering Index (CRI) | 85 |
| Approximate Ship Weight (lbs) | 1 |
