TCM180 12 led RGB

$279.00

Brands: LUMIRON™

SKU: N/A Categories: ,
Loading...

Description

TCM180 12 LED RGB

LED LIGHTING DOWNLIGHTS TCM180 12 LED RGB is  Ideal for boat, yacht, RVs, motor home and more.  Featuring 4-wire power & dimming, TCM180 12  fixtures easily replace existing legacy (halogen) spots negating the need to run extra wires. Integrated drive electronics eliminates the need for remote driver installation. Carefully designed optics result in fully blended illumination free of annoying artifacts or distracting hot spots.

A robust thermal management system results in maximum life with minimal lumens depreciation over its expected working life (50,000+ hrs). These fixtures feature a traditional raised-round bezel in several finishes. The  securely mounted with three screws and are ideal for hard ceilings (e.g. fiberglass or wood). It is a good choice for wet areas (e.g. hard tops, arches, walkway overhangs, shower stalls). Made in the USA and covered by a 5 year warranty!

VIEW MORE DOWNLIGHTS

Product Specs

Weight 1 lbs
Color Led

Red, Green, Blue

Input Voltage

12V DC, 24V DC

Mounting / Cut

5.10″ (130mm)

Trim Ring (Bezel)

7.09″ (180mm)

IP Rating

IP65

Brand

LUMIRON

Technical data

No. LEDs 12 RGB
Certifications & Compliance CE-EMC, ROHS
Integrated Switch No
Lifetime Hours 50,000 hrs
Class Class III
Dimmer Control Interface Momentary Push-Button
Cut-out Dimensions 5.10″ (130mm)
Trim Ring (Bezel) Dimensions 7.09″ (180mm)
Halogen Equivalency 25W
Input Voltage 10-40VDC
Warranty 5 Years / 1 Year Finish
Lens Material Frosted glass
Recessed Depth 1.08″ (27mm)
Ingress Protection IP65 (applies only to frontal water exposure, i.e. Exposed surface)
Dimming Range 5-100%
Luminous Flux 206 lms
Driver Integrated
Install Location Exterior (hard tops, overhangs, showers)
Electrical Protections Reverse Polarity, Transient & Spike Protection
Color Rendering Index (CRI) 85
Approximate Ship Weight (lbs) 1
