Power Supply Rechargeable 24V Lithium Ion Battery

Power Supply Rechargeable 24V Lithium Ion Battery

The LUMIRON Power Supply Rechargeable 24V Lithium-Ion Battery seamlessly integrates with our Light bars, Flexible LED Lights, and most 24V/12V/5V DC electronic devices. You can recharge the Lithium-Ion Battery Pack without limitations, thanks to its design for a slow charge process (full charge in 5 hours), ensuring an extended battery pack lifespan. Utilize the Power Supply to effortlessly power LUMIRON’s Custom LED Light Panels.

Benefits

  • Capacity: 3.7V/22400mAh 82.88Wh
  • Build-in battery: High quality lithium ion batteries (18650)
  • Input: 29.4V/0.95A.
  • USB: 5V/2A Max. DC port: 24V（29.4V-21V）/3A Max. 12V/2A Max.
Power Supply Electronic 320W 12V

Power Supply Electronic 320W 12V

The LUMIRON Power Supply Electronic 320W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000PS – 4306D (Dimmable)
  2. Model: LMPG – 320W – 12VDC – D
  3. Maximum Input Current: 3.5A
  4. Output Connector Type: Stripped and Tinned
  5. Number of Outputs: 1
  6. Product Type: AC to DC Power Supply
  7. Efficiency: 91% Minimum
  8. Isolation Voltage: 3750V
  9. Operating Temperature-Min: -40c
  10. Operating Temperature-Max: 70c
  11. Length: 9.92″ (252mm)
  12. Width: 3.54″ (90mm)
  13. Height: 1.72″ (43.8mm)
  14. Agency Approvals: UL/CUL/TUV/CB/CE
  15. Type: Auto Switching
  16. Style: Enclosed Primary
  17. Primary Output Voltage: 12VDC
  18. Output Current: 22A
  19. Maximum Output Power: 264W
  20. Input Voltage: 90 to 305VAC
  21. Input Frequency: 47 to 63
Power Supply Electronic 320W 24V

Power Supply Electronic 320W 24V

The LUMIRON Power Supply Electronic 320W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000PS – 4306D (Dimmable)
  2. Model: LMPG – 320W – 24VDC – D
  3. Maximum Input Current: 3.5A
  4. Output Connector Type: Stripped and Tinned
  5. Number of Outputs: 1
  6. Product Type: AC to DC Power Supply
  7. Efficiency: 94% Minimum
  8. Isolation Voltage: 3750V
  9. Operating Temperature-Min: -40c
  10. Operating Temperature-Max: 70c
  11. Length: 9.92″ (252mm)
  12. Width: 3.54″ (90mm)
  13. Height: 1.72″ (43.8mm)
  14. Agency Approvals: UL/CUL/TUV/CB/CE
  15. Type: Auto Switching
  16. Style: Enclosed Primary
  17. Primary Output Voltage: 24VDC
  18. Output Current: 13.3A
  19. Maximum Output Power: 264W
  20. Input Voltage: 90 to 305VAC
  21. Input Frequency: 47 to 63
Power Supply Universal 60W 12V

Power Supply Universal 60W 12V

The LUMIRON Power Supply Universal 60W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4500
  2. Model: LMPS60S12VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.4A
  6. Output Current: 5A
  7. Maximum Output Power: 60 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 4.9″ x W 1.9″ x H 1.2″ / L ( 12.5cm ) x W ( 4.9cm ) x H ( 3.1cm )
Power Supply Universal 60W 24V

Power Supply Universal 60W 24V

The LUMIRON Power Supply Universal 60W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4501
  2. Model: LMPS60S24VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63 / 1.4A
  5. Output Current: 2.5A
  6. Maximum Output Power: 60 Watts
  7. Output Connector Type: Cylindrical Female
  8. Output Connector Diameters: 2.1mm x 5.5mm
  9. Efficiency: 88%
  10. Type: Switching
  11. Style: Desktop Adapter
  12. Case: Fully enclosed plastic case
  13. Protections: Short circuit / Overload / Over voltage / Over temperature
  14. Size: L 4.9″ x W 1.9″ x H 1.2″ / L ( 12.5cm ) x W ( 4.9cm ) x H ( 3.1cm )
Power Supply Universal 120W 12V

Power Supply Universal 120W 12V

The LUMIRON Power Supply Universal 120W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4502
  2. Model: LMPS120S12VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.4A
  6. Output Current: 8.5A
  7. Maximum Output Power: 102 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 6.57″ x W 2.63″ x H 1.37″ / ( 16.7cm ) x W ( 6.7cm ) x H ( 3.5cm )
Power Supply Universal 120W 24V

Power Supply Universal 120W 24V

The LUMIRON Power Supply Universal 120W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4503
  2. Model: LMPS120S24VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.4A
  6. Output Current: 5A
  7. Maximum Output Power: 122 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 91%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 6.67″ x W 2.63″ x H 1.37″ / ( 16.7cm ) x W ( 6.7cm ) x H ( 3.5cm )
Power Supply Universal 90W 12V

Power Supply Universal 90W 12V

The LUMIRON Power Supply Universal 90W 12V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4510
  2. Model: LMPS90S12VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 2.6A
  6. Output Current: 5A
  7. Maximum Output Power: 90 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 5.71″ x W 2.36″ x H 1.26″ / L ( 14.5cm ) x W ( 6.0cm ) x H ( 3.2cm )
Power Supply Universal 90W 24V

Power Supply Universal 90W 24V

The LUMIRON Power Supply Universal 90W 24V is a transformer module designed to produce outstanding dimmable lighting solutions.

  1. Part Number: 7000 – PS – 4511
  2. Model: LMPS90S24VDC-UN
  3. Input Voltage: 90 to 264 VAC
  4. Input Frequency: 47 to 63
  5. Maximum Input Current: 1.3A
  6. Output Current: 3.75A
  7. Maximum Output Power: 90 Watts
  8. Output Connector Type: Cylindrical Female
  9. Output Connector Diameters: 2.1mm x 5.5mm
  10. Efficiency: 88%
  11. Type: Switching
  12. Style: Desktop Adapter
  13. Case: Fully enclosed plastic case
  14. Protections: Short circuit / Overload / Over voltage / Over temperature
  15. Size: L 5.71″ x W 2.36″ x H 1.26″ / L ( 14.5cm ) x W ( 6.0cm ) x H ( 3.2cm )
DMR 3007 PB 1 Zone Dimmer Receiver Amplifier

DMR 3007 PB 1 Zone Dimmer Receiver Amplifier

It is a wireless dimming and ON/OFF system for any LED Product that works at 12VDC, 24VDC, or 36VDC. The 800mhz wireless remote can be placed anywhere and works as an ON/Off switch and dimmer with just one button. Easily adjust your LED Lights to your preferred brightness level and the unit will memorize the setting, so next time you turn on the lights they will light up at exactly the same level they were before they were turned off. The DMR 3007 PB 1 Zone Dimmer Receiver Amplifier product includes a PUSH BUTTON WIRELESS DIMMER and one UL Listed RECEIVER ensuring the safety and durability for the lifetime of the receiver. It is IP20, please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a waterproof enclosure. Always be sure to mount it in an area with proper ventilation to avoid overheating. It is easy to install and operate and will provide many years of easy operation. The operation is very simple: Press the center button on the remote for less than 1 second to turn On or OFF. Press and hold the button to Increase/Decrease brightness.

Main Features

  • Ultra compact Wireless Dimmer remote (1.51in x 0.70in)
  • Battery included with remote
  • On/Off function
  • 0-100% dimming
  • 4 X 120W Outputs (total 480W @24VDC)
  • Memory function (keeps settings even if power loss)
  • Ultra smooth dimming
  • Remote Control unit can be hidden almost everywhere
  • Up to 30 feet control distance (Unobstructed)
